SWOOD Woodworking : a 3D CAD CAM to empower SOLIDWORKS users for designing CAM and Nesting applications which exclusive for woodworking. SWOOD is support for programming and production documentation through SOLIDWORKS.
SWOOD From design to manufacturing
SWOOD Overview
3D CAD CAM for Woodworking
Boost your SOLIDWORKS woodworking projects with SWOOD Design, CAM and Nesting. Create your programs and manufacturing documents directly into SOLIDWORKS with full associativity.
- Streamline the process from CAD to Machine
- Export more information to production
- Capabilities to develop new products range
- Producing product quality
SWOOD – WOODWORKING CAD/CAM
SWOOD Design : Features for woodworking inside SOLIDWORKS
SWOOD Design makes it easier to achieve your woodworking projects. Design faster, just drag & drop.
Benefit
- Design faster
- Production ready design (Reliability, design rules homogenized)
- Storage of customized and reusable parametric items
- Woodworking dedicated reporting
Tools in SWOOD Design
- Edge banding Management
- Molding positioning
- Parametric panel library
- Material library, including decor or grain direction
- Cabinet Design – Copy a frame from your library and fill it dragging.
- Fill your furniture with elements (doors, drawers, shelves …), including hardware and machining of adjacent parts.
- Connectors include traditional (mortise & tenon) or mechanical (swivel pins, cams) types of joint.
- Fittings – Insert your cabinet and link its dimensions to a layout sketch.
SWOOD Rendering Gallery
SWOOD CAM : Machining and producing woodworking inside SOLIDWORKS
SWOOD CAM manages NC machines dedicated to woodworking and their technologies. Create your programs and production documents directly inside SOLIDWORKS.
Benefits
- Native management of the woodworking machinery technologies
- Easy to use
- Associativity with SWX models and machining rules based on SWX models
- Storage of reusable machining strategies
- Export of full project data (cut list, tool list, cup position, programs, …)
Tools in SWOOD CAM
- Customise NC machine code
- Machining macros library
- Automatic worktable management
- Multiple positioning
- Batch encoding and manufacturing documents export on full project
- Automatic and optimised drilling with drilling aggregate
- Manufacturing treeview in Feature Manager
- Tools, Aggregates and Machining Macros libraries in Task Pane
- Insert library items by drag-and-drop
- A large amount of NC machines already managed thanks to customisable machine code
- Customised production documents generated (Cut list, Hardware list, Labels)
- Full associativity between SOLIDWORKS geometric entities and machining
- Additional machining rules defined using configuration, custom properties and features status.
- Automatic and optimized drilling with drilling aggregate with full associativity.
